Latex Printing Solution for PU/PVC Leather
Project Background

Latex ink printing has always been a product of an imported American brand. Due to limitations in printing costs, printing effects and other reasons, it has always been a very niche product application in the inkjet industry. However, with the development of the industry in recent years, higher requirements have been put forward for digital inkjet printing. The characteristics of latex ink, such as water-based environmental protection and strong functionality, are important directions for the future development of the industry......

Leather Printng Show
Customer Pain Point
There is no way to print images directly on uncoated media with normal water-based inks, let alone the fastness. The biggest functional advantage of water-based latex inks is that they can print images on uncoated media and achieve extremely high fastness. Spend.
Leather Printing Solution Advantages


  • Use mesh belt platform to feed the printing material, adopts industrial grade high-power fans to guarantee smooth transmission.
  • The partitioned and adjustable powerful air suction function, can feed the printing material smoothly and falt, totally avoiding the deformation, wrinkle, sticking, scratching during printing.
  • Suit for different kinds of media, especially the materials with specific thickness, hardness and stretchability, all can be printed with this printer. This high value-added printing solution is more Eco-friendly,can greatly expand user’s business scope.
  • Imported linear guide rail;Germany imported wires; imported high-power AC servo motor; Carriage anti-collision device; Fully automatic ink supplying & alarming system.
Latex Printer Specification
Printing Specifications
Computer Configuration
Printhead
EPSON I32100-A1 Compputer CPU: i5 internal storage > 8GB
Printhead No.
3-4 System Win7 / Win 10
Output Precision
360*1800dpi     720*1080dpi    720*2400dpi Interface USB
Printing Speed OP+W+Color OP+W+Color+Color Software MainTop, PhotoPrint
Economy Mode 22m2/h 34m2/h Power Source AC-220V, 50Hz / 60Hz
Production Mode 16m2/h 25m2/h Power 3KW
Quality Mode 13m2/h 20m2/h Packaging Specifications
Ink Configration Machine Dimension 3760 * 1130 * 1600mm (L * W * H)
Ink Type Water-based eco-friendly latex ink Net Weight 1000kg
Color KCMY (LC/LM/R/B/OR/FM/FY for optional) + W + OP Package Dimension 3800 * 1180 * 1650mm (L * W * H)
Ink Supply Big capacity ink supplying system + ink shortage alarm + white ink circulation Gross Weight 1100kg
Latex Printing Solution Value
Hongsam JETALL water-based latex ink is environmentally friendly. There is no odor either during the printing process or in the finished product. It effectively improves the environmental quality of the product and caters to market needs. It improves the production environment and reduces labor risks. There are no flammable consumables, which reduces production fire risks. . It has the advantages of adapting to the diversity of printing media and image durability, and is especially suitable for industries with extremely high environmental requirements such as decoration, wallpapers and murals. It is a functional ink that represents the future direction of inkjet printing.
